ST76L

High efficient, stainless steel LED floodlights for decks, holds, industrial areas, IP67

Part no.ST76 L 3x 22°    5101005710-001
ST76 L 3x 37°    5101005710-000
ST76 L 3x 52°    5101005710-002
ST76 L 3x 91°    5101005710-019
DesignAccording to rules of maritime classification societies and relevant standards
HousingStainless steel, 1.4404 (AISI 316L) seamless deep drawn
powder coated white (RAL9016)
Safety paneTempered glass, DIN 12150, partially lacquered
MountingStainless steel bracket, adjustable
ReflectorAluminium reflectors with spherical facets, interference-colors free
Cable entryExterior connection box, cable gland M20
Protection classIP67
Weight9.5 kg
Light source3x LED array
Wattage3x 25 W
CCT (color)5,700 K
CRI≥ 80
Voltage110-240 V AC
Frequency50-60 Hz
ST76L
Spare Parts                                Part no.
LED array kit7409003000
Connection type unit 2x 25 W7305000700
Connection type unit 1x 25 W7305000800
Cover w. frame7902002600
Bracket7501000100
Reflector kit 22°7901003400
Reflector kit 37°7901003500
Reflector kit 51°7901003600
Reflector kit 92°7901003700

Extras

  • 24 V DC
  • Safety pane partially satined
  • Different cable glands on request
  • Reflectors with different beam angles can be combined
  • Different color temperatures on request
