Ceiling luminaires >>> LED
  • DA Flex S

DA Flex S

Ceiling LED luminaire, surface mounting for passage ways, cabins, lounges, accommodation areas

Design According to rules of maritime classification societies, additional VDE and IEC
Housing Galvanized steel, powder coated white (RAL9016)
Diffuser Opal polycarbonate
Mounting Mounting holes 4x Ø 6 mm
Cable entry 30 x 16 mm or 2x grommets
Protection class IP20 or IP44
Weight 2.0 kg
Wattage Max. 16 W
CCT (color) 3,000 K
Luminous flux 1,800 lm
CRI ≥ 80
Voltage 220-240 V AC
Frequency 50-60 Hz
IP20
DA Flex S
IP44
DA Flex S
Part No.
DA Flex S  IP20 5112008800-005
DA Flex S IP44 5112010600-001

Extras

  • Motion sensor
  • 120 V AC execution
  • 24 V DC execution
  • Dimmable
  • Different color temperatures

Downloads

Datasheet – DA Flex S (PDF) DA_FLEX_S_1x16W_4000K_80_-_PC_OPAL_LED.ldt
