DL85

Watertight LED downlight for bathrooms, accommodation and public areas

Design According to rules of maritime classification societies and relevant standards
Housing Aluminium
Decorative ring White (RAL9016)
Cover Polycarbonate clear or opal
Mounting 2 fixing springs for ceilings max. 35 mm
Connection type Connection cable with Wago 3-pole plug
Protection class IP20 / IP55 in conjunction with ceiling
Weight 0.3 kg
Light source LED array
Wattage Eco: max. 6 W
HO: max. 12 W
CCT (color) 2,700 K
CRI ≥ 90
Voltage 230 V AC
Frequency 50-60 Hz
DL85
Part No. Beam Type Lumen
5306007400-001 20° Eco 750 lm
5306007400-002 40° Eco 750 lm
5306007400-003 60° Eco 750 lm
5306007400-004 Opal Eco 550 lm
5306007500-001 20° HO 1200 lm
5306007500-002 40° HO 1200 lm
5306007500-003 60° HO 1200 lm
5306007500-004 Opal HO 850 lm

Extras

  • Black baffle
  • Ring in chrome
  • Dimmable DALI or 1–10 V
  • 120 V AC execution
  • Different color temperatures
  • Different connectors
