SP66S

Mirror luminaire, LED, for cabins, bathrooms, lavatories and accommodation areas

Design	According to rules of maritime classification societies and relevant standards
Housing	Galvanized steel, powder coated white (RAL9016)
End caps	Polycarbonate, white
Diffuser	Polycarbonate opal, structured
Switch	On / off switch, 2-pole (optional)
Mounting	2 mounting holes, Ø 5.5 mm
Cable entry	2x grommets
Protection class	IP44
Light source	Linear LP LED module
Wattage	Max. 6 W
CCT (color)	3,000 K
Luminous flux	700 lm
CRI	≥ 80
Voltage	120–230 V AC
Frequency	50–60 Hz
