Design | According to rules of maritime classification societies and relevant standards |
Housing | Galvanized steel, powder coated white (RAL9016) |
End caps | Polycarbonate, white |
Diffuser | Polycarbonate opal, structured |
Switch | On / off switch, 2-pole (optional) |
Mounting | 2 mounting holes, Ø 5.5 mm |
Cable entry | 2x grommets |
Protection class | IP44 |
Light source | Linear LP LED module |
Wattage | Max. 6 W |
CCT (color) | 3,000 K |
Luminous flux | 700 lm |
CRI | ≥ 80 |
Voltage | 120–230 V AC |
Frequency | 50–60 Hz |
Part no. | |
---|---|
SP66S | 5115006100-005 |
SP66S with switch | 5115006100-006 |
SP66S with socket | 5115006100-007 |
SP66S with switch and socket | 5115006100-008 |
