Design | According to rules of maritime classification societies and relevant standards |
Housing | Polycarbonate, black |
Decorative frame | Zinc coated steel, powder coated white (RAL9016) |
Mounting | Swiveling insert for ceilings up to 20 mm |
Connection type | Connection cable with Wago 3-pole plug |
Protection class | IP20 |
Weight | Depends on execution |
Light source | LED module |
Wattage | Max. 13 W / module |
CCT (color) | 3,000 K |
CRI | ≥ 80 |
Voltage | 220-240 V AC |
Frequency | 50-60 Hz |
Part No. | |
---|---|
DL110Q 1 module | 5404001200-002 |
DL110Q 2 modules | 5404001300-002 |
DL110Q 3 modules | 5404001400-002 |
