DL63

LED Downlight with changeable cover ring, for cabins, accommodation and public areas

Design According to rules of maritime classification societies and relevant standards
Housing Galvanized steel, powder coated white (RAL9016)
Decorative ring RAL9016, chrome or steel brushed (has to be ordered separately, see datasheet page 2)
Mounting Max. 6 mounting holes, Ø 4.5 mm
Connection type Connection cable with Wago 3-pole plug
Protection class IP20 / IP44 with lens
Weight DL63S: 0.9 kg
DL63M: 1.1 kg
DL63L: 1.2 kg
Light source LED module
Wattage DL63S: max. 5 W
DL63M: max. 10 W
DL63L: max. 20 W
CCT (color) 3,000 K
Luminous flux DL63S: 500 lm (with satined glass)
DL63M: 1,000 lm (with satined glass)
DL63L: 2,000 lm (with satined glass)
CRI ≥ 80
Voltage 220-240 V AC
Frequency 50-60 Hz
DL63
Part No.
DL63S 5503002500-xxx
DL63M 5503002600-xxx
DL63L 5503002700-xxx
Spare Parts Part No.
Female connector Wago 7124001800

Extras

  • 120 V AC execution
  • Different connectors
  • Different color temperatures
  • Dimmable
  • Emergency battery back-up
