Design | According to rules of maritime classification societies and relevant standards |
Housing | Stainless steel, powder coated black |
Decorative ring | Stainless steel, glossy |
Cover | Clear glass |
Mounting | 3 mounting holes Ø 4 mm, for ceilings max. 20mm |
Cable entry | Cable gland brass for cables Ø 4-8 mm |
Connection type | Connection cable with Wieland 3-pole plug |
Protection class | IP65 |
Weight | 1.6 kg |
Light source | LED (lamp not included) |
Lamp base | GU5.3 |
Wattage | Max. 10 W |
Voltage | 230 V AC |
Frequency | 50-60 Hz |
Part No. | |
---|---|
DL67 | 5301010300-061 |
