Design | According to rules of maritime classification societies and relevant standards |
Housing | Gear tray stainless steel 1.4401 (AISI 316L), powder coated RAL9016. Back side covered with opal PC hood |
Safety pane | Tempered glass, DIN 12150, clear |
Mounting | Stainless steel bracket, adjustable |
Cable entry | IDC fast connection, 1x Cable Ø 9-14mm |
Protection class | IP66/67 |
Weight | 11 kg |
Light source | 4x LED engine |
Wattage | 4x 55 W |
Equivalent | 400 W HST/HIT |
CCT (color) | 5,700 K |
Luminous flux | 30,000 lm |
Voltage | 120-277 V AC |
Frequency | 50 - 60 Hz |
Part No. | |
---|---|
ST81 L 4x 22° | 5101008900-001 |
ST81 L 4x 37° | 5101008900-002 |
ST81 L 4x 52° | 5101008900-003 |
ST81 L 4x 91° | 5101008900-004 |
SPARE PARTS | PART NO. |
---|---|
PC hood | 7502008000 |
Bracket | 7501000100 |
Cable entry | 7211004800 |
