Design | According to rules of maritime classification societies and relevant standards |
Housing | Steel, white (RAL9010) |
Cover/diffuser | Polycarbonate |
Lens | Biconvex glass lens, Ø 120 m, 3 diopters (1,75 x power) |
Switch | In lighting head |
Mounting | Table mounting |
Connection type | Connection cable with Euro plug |
Protection class | IP20 |
Weight | 2.0 kg |
Light source | LED |
Wattage | Max. 5.3 W |
CCT (color) | 5,000 K |
CRI | ≥ 80 |
Voltage | 100–240 V AC |
Frequency | 50–60 Hz |
Electrical execution | Dimmable in three steps 30% / 80% / 100% |
Part No. | |
---|---|
TI20 | 5135012400-001 |
